Stud Tensioning Internal Adjuster System

Cancealed Thread Cable Rail Stud Tensioning Adjuster System
stud tensioning
Concealed Thread Cable Rail
Stud Tensioning Adjuster System is a simple and economical cable tensioning system that provides for a “clean” look by concealing the threads for adjustment internally. The typical application is for cable runs less than 40 feet in wire sizes ranging from 1/8″ to 1/4″. All hardware is made from high quality 316 grade stainless steel for superior corrosion resistance. Additionally, the stud tensioners can be used in conjunction with other stud length combinations and systems to meet your design criteria. System Notes:
  1. Maximum run based on use with nonadjustable Termination Stud end.  Maximum run doubles when Stud Tensioners used on both ends.
  2. System engineered as a “through post” application.
  3. Stair angle compensation achieved with use of Bevel Washers or Adjust-A-Ball hardware options. See Angle Compensation and Termination Accessories.
  4. Longer runs achieved with use of Intermediate Turnbuckle Assemblies.

Machine Swage – factory assembled to field dimensions
Hex Key Wrench Size – 3/16″ for all versions listed

Part # Wire Size Thread Size L-Length C-FULLY CLOSED O-FULLY OPEN B-BODY DIAMETER Adjustment Range Max. Run Length each
ST06A18 1/8″ 1/4-28 1-1/2″ 1-5/8″ 2-3/8″ 5/16″ 3/4″ 20′
ST06AM03 3mm 1/4-28 1-1/2″ 1-5/8″ 2-3/8″ 5/16″ 3/4″ 20′
ST06A532 5/32″ 1/4-28 1-1/2″ 1-3/4″ 2-1/2″ 5/16″ 3/4″ 20′
ST06AM04 4mm 1/4-28 1-1/2″ 1-3/4″ 2-1/2″ 5/16″ 3/4″ 20′
ST06A316 3/16″ 1/4-28 1-1/2″ 1-3/4″ 2-1/2″ 5/16″ 3/4″ 20′
ST06AM05 5mm 1/4-28 1-1/2″ 1-3/4″ 2-1/2″ 5/16″ 3/4″ 20′
ST08A532 5/32″ 5/16-24 1-1/2″ 1-3/4″ 2-1/2″ 3/8″ 3/4″ 20′
ST08AM04 4mm 5/16-24 1-1/2″ 1-3/4″ 2-1/2″ 3/8″ 3/4″ 20′
ST08A316 3/16″ 5/16-24 1-1/2″ 1-3/4″ 2-1/2″ 3/8″ 3/4″ 20′
ST08AM05 5mm 5/16-24 1-1/2″ 1-3/4″ 2-1/2″ 3/8″ 3/4″ 20′
ST08A14 1/4″ 5/16-24 1-1/2″ 1-3/4″ 2-1/2″ 3/8″ 3/4″ 20′
ST08AM06 6mm 5/16-24 1-1/2″ 1-3/4″ 2-1/2″ 3/8″ 3/4″ 20′

Hayn Grip™ – on site install

Part # Wire Size Thread Size Length C-FULLY CLOSED O-FULLY OPEN B-BODY DIAMETER ADJUSTMENT RANGE Max. Run Length each
ST06A18-HG 1/8″ 1/4-28 1-1/2″ 2-1/8″ 2-7/8″ 5/16″ 3/4″ 20′
ST06AM03-HG 3mm 1/4-28 1-1/2″ 2-1/8″ 2-7/8″ 5/16″ 3/4″ 20′
ST06A532-HG 5/32″ 1/4-28 1-1/2″ 2-1/8″ 2-7/8″ 5/16″ 3/4″ 20′
ST06AM04-HG 4mm 1/4-28 1-1/2″ 2-1/8″ 2-7/8″ 5/16″ 3/4″ 20′
ST08A316-HG 3/16″ 5/16-24 1-1/2″ 2-1/8″ 2-7/8″ 3/8″ 3/4″ 20′
ST08AM05-HG 5mm 5/16-24 1-1/2″ 2-1/8″ 2-7/8″ 3/8″ 3/4″ 20′

Handy Crimp™ – on site install

Part # Wire Size Thread Size C-FULLY CLOSED O-FULLY OPEN B-BODY DIAMETER ADJUSTMENT RANGE Max. Run Length each
ST06A18C 1/8″ 1/4-28 2″ 2-3/4″ 5/16″ 3/4″ 20′
ST06A316C 3/16″ 1/4-28 1-7/8″ 2-5/8″ 5/16″ 3/4″ 20′
ST08A316C 3/16″ 5/16-24 1-7/8″ 2-5/8″ 3/8″ 3/4″ 20′
