Machine Swage – factory assembled to field dimensions
Part # | Thread | W – Wire Size | D-Hole Diameter | HS-Hole Spacing | O-Open L | C-Closed L | L-Body L | F-Jaw Width | Weight lbs. | Max Run Length |
---|---|---|---|---|---|---|---|---|---|---|
14TTLL18DT | 1/4-28 | 1/8″ | 1/4″ | 1 1/2″ | 9 7/32″ | 6 7/32″ | 4 1/4″ | 21/32″ | 0.18 | 50′ |
14TTLL532DT | 1/4-28 | 5/32″ | 1/4″ | 1 1/2″ | 9 3/8″ | 6 3/8″ | 4 1/4″ | 21/32″ | 0.22 | 50′ |
14TTLL316DT | 1/4-28 | 3/16″ | 1/4″ | 1 1/2″ | 9 3/8″ | 6 3/8″ | 4 1/4″ | 21/32″ | 0.22 | 50′ |
516TTLL316DT | 5/16-24 | 3/16″ | 5/16″ | 1 3/4″ | 10 1/4″ | 7″ | 5″ | 3/4″ | 0.33 | 50′ |
516TTLL14DT | 5/16-24 | 1/4″ | 5/16″ | 1 3/4″ | 10 3/8″ | 7 1/8″ | 5″ | 3/4″ | 0.40 | 50′ |
38TTLL14DT | 3/8-24 | 1/4″ | 3/8″ | 2″ | 11 11/16″ | 7 15/16″ | 5 1/2″ | 57/64″ | 0.54 | 50′ |
Hayn Grip™ – on site install
Part # | Thread | W – Wire Size | D – Hole Diameter | HS – Hole Spacing | Adjustment Range | Max. Run Length |
---|---|---|---|---|---|---|
14TTHG18DT | 1/4-28 | 1/8″ | 1/4″ | 1-1/2″ | 3″ | 50′ |
14TTHG316DT | 1/4-28 | 3/16″ | 1/4″ | 1-1/2″ | 3″ | 50′ |
Handy Crimp™ – on site install
Part # | Thread | W – Wire Size | D – Hole Diameter | HS – Hole Spacing | Adjustment Range | Max. Run Length |
---|---|---|---|---|---|---|
14TTCLL18DT | 1/4-28 | 1/8″ | 1/4″ | 1-1/2″ | 3″ | 50′ |
14TTCLL316DT | 1/4-28 | 3/16″ | 1/4″ | 1-1/2″ | 3″ | 50′ |
516TTCLL316DT | 5/16-24 | 3/16″ | 5/16″ | 1-3/4″ | 3-1/4″ | 50′ |
Wood Lag Screws – Hex Head are available.
Machine Swage – factory assembled to field dimensions
Part # | D – Hole dIameter | W – Wire Size | HS – Hole Spacing |
---|---|---|---|
14TJLL18DT | 1/4″ | 1/8″ | 1-1/2″ |
14TJLL532DT | 1/4″ | 5/32″ | 1-1/2″ |
14TJLL316DT | 1/4″ | 3/16″ | 1-1/2″ |
516TJLL316DT | 5/16″ | 3/16″ | 1-3/4″ |
516TJLL14DT | 5/16″ | 1/4″ | 1-3/4″ |
38TJLL14DT | 3/8″ | 1/4″ | 2.0″ |
Hayn Grip™ – on site install
Part # | D – Hole Diameter | W – Wire Size | HS – Hole Spacing |
---|---|---|---|
14TJHG18DT | 1/4″ | 1/8″ | 1-1/2″ |
14TJHG316DT | 1/4″ | 3/16″ | 1-1/2″ |
Handy Crimp™ – on site install
Part # | D – Hole Diameter | W – Wire Size | HS – Hole Spacing |
---|---|---|---|
14TJCLL18DT | 1/4″ | 1/8″ | 1-1/2″ |
14TJCLL316DT | 1/4″ | 3/16″ | 1-1/2″ |
