| Part # | W-Wire Ø | D-Hole Ø | H-Hardware Factor | J-Eye Width | Weight lbs. |
|---|---|---|---|---|---|
| ME2 | 1/16″ | 1/4″ | 3/4″ | 7/32″ | 0.03 |
| ME3 | 3/32″ | 1/4″ | 13/16″ | 7/32″ | 0.03 |
| ME4 | 1/8″ | 1/4″ | 11/16″ | 7/32″ | 0.04 |
| ME5A | 5/32″ | 1/4″ | 11/16″ | 7/32″ | 0.04 |
| ME5 | 5/32″ | 5/16″ | 13/16″ | 1/4″ | 0.05 |
| ME6A | 3/16″ | 5/16″ | 3/4″ | 1/4″ | 0.1 |
| ME6 | 3/16″ | 3/8″ | 15/16″ | 5/16″ | 0.09 |
| ME7DS | 7/32″ | 3/8″ | 1 1/8″ | 5/16″ | 0.16 |
| ME7 | 7/32″ | 7/16″ | 1 1/8″ | 3/8″ | 0.17 |
| ME8A | 1/4″ | 3/8″ | 7/8″ | 5/16″ | 0.19 |
| ME8DS | 1/4″ | 7/16″ | 1 5/32″ | 3/8″ | 0.24 |
| ME8 | 1/4″ | 1/2″ | 1 1/8″ | 3/8″ | 0.22 |
| ME9 | 9/32″ | 1/2″ | 1 3/32″ | 15/32″ | 0.28 |
| ME10A | 5/16″ | 1/2″ | 1 3/16″ | 1/2″ | 0.37 |
| ME10 | 5/16″ | 5/8″ | 1 5/16″ | 1/2″ | 0.44 |
| ME10B | 5/16″ | 9/16″ | 1 3/16″ | 1/2″ | 0.41 |
| ME12 | 3/8″ | 5/8″ | 1 9/16″ | 9/16″ | 0.57 |
| ME14 | 7/16″ | 3/4″ | 1 15/16″ | 11/16″ | 0.99 |
| ME16A | 1/2″ | 3/4″ | 2 7/32″ | 11/16″ | 1.25 |
| ME16 | 1/2″ | 7/8″ | 2 1/16″ | 7/8″ | 1.12 |
| ME18 | 9/16″ | 7/8″ | 2 1/4″ | 13/16″ | 1.65 |
| ME20 | 5/8″ | 1″ | 2 5/16″ | 15/16″ | 2.32 |
| ME24 | 3/4″ | 1 1/8″ | 2 1/2″ | 1 1/32″ | 4.14 |
| ME28 | 7/8″ | 1 1/4″ | 3 7/16″ | 1 3/16″ | 6.55 |
| ME32 | 1″ | 1 3/8″ | 3 1/2″ | 1 3/8″ | 8.95 |
| Part # | W-Wire Ø | D-Hole Ø | H-Hardware Factor | J-Eye Width | Weight lbs. |
|---|---|---|---|---|---|
| MEM03 | 3mm | 1/4″ | 11/16″ | 7/32″ | 0.03 |
| MEM03-CS | 3mm | 1/4″ | 11/16″ | 7/32″ | 0.03 |
| MEM04 | 4mm | 5/16″ | 13/16″ | 1/4″ | 0.05 |
| MEM04-CS | 4mm | 5/16″ | 13/16″ | 1/4″ | 0.05 |
| MEM05 | 5mm | 3/8″ | 15/16″ | 5/16″ | 0.09 |
| MEM05-CS | 5mm | 3/8″ | 15/16″ | 5/16″ | 0.09 |
| MEM06A | 6mm | 3/8″ | 7/8″ | 5/16″ | 0.12 |
| MEM06 | 6mm | 1/2″ | 1 1/8″ | 3/8″ | 0.22 |
| MEM06-CS | 6mm | 1/2″ | 1 1/8″ | 3/8″ | 0.24 |
| MEM07 | 7mm | 1/2″ | 1 3/32″ | 15/32″ | 0.28 |
| MEM07-CS | 7mm | 1/2″ | 1 3/32″ | 15/32″ | 0.32 |
| MEM08A | 8mm | 1/2″ | 1 3/16″ | 1/2″ | 0.44 |
| MEM08A-CS | 8mm | 1/2″ | 1 3/16″ | 1/2″ | 0.43 |
| MEM08 | 8mm | 5/8″ | 1 5/16″ | 1/2″ | 0.37 |
| MEM08-CS | 8mm | 5/8″ | 1 5/16″ | 1/2″ | 0.49 |
| MEM10 | 10mm | 5/8″ | 1 9/16″ | 9/16″ | 0.57 |
| MEM10-CS | 10mm | 5/8″ | 1 9/16″ | 9/16″ | 0.65 |
| MEM10US-CS | 10mm | 3/4″ | 2 1/16″ | 11/16″ | 0.89 |
| MEM11 | 11mm | 3/4″ | 1 15/16″ | 11/16″ | 0.99 |
| MEM12 | 12mm | 3/4″ | 2 7/32″ | 11/16″ | 1.12 |
| MEM12-CS | 12mm | 3/4″ | 2 7/32″ | 11/16″ | 1.26 |
| MEM12US | 12mm | 7/8″ | 2 1/16″ | 7/8″ | 1.32 |
| MEM12US-CS | 12mm | 7/8″ | 2 1/16″ | 7/8″ | 1.40 |
| MEM14 | 14mm | 7/8″ | 2 1/4″ | 13/16″ | 1.65 |
| MEM14-CS | 14mm | 7/8″ | 2 1/4″ | 13/16″ | 1.84″ |
| MEM14US-CS | 14mm | 1″ | 1 1/2″ | 15/16″ | 2.06″ |
| MEM16 | 16mm | 1″ | 2 5/16″ | 15/16″ | 2.32 |
| MEM16-CS | 16mm | 1″ | 2 5/16″ | 15/16″ | 2.47 |
| MEM16US-CS | 16mm | 1 1/8″ | 2 11/16″ | 1 1/16″ | 2.91 |
| MEM19 | 19mm | 1 1/8″ | 2 1/2″ | 1 1/32″ | 4.14 |
| MEM19-CS | 19mm | 1 1/8″ | 2 1/2″ | 1 1/32″ | 4.14 |
| MEM19US-CS | 19mm | 1 1/4″ | 3 7/16″ | 1 3/16″ | 5.47 |
| MEM22 | 22mm | 1 1/4″ | 3 7/16″ | 1 3/16″ | 6.55 |
| MEM26 | 26mm | 1 3/8″ | 3 1/2″ | 1 3/8″ | 8.95 |
