1×19 / 1×37 Stainless Steel Wire
| Part # | Wire Diameter | Strand Configuration | Per Foot or Spool Size | Minimum Breaking Strength LBS |
|---|---|---|---|---|
| SC06219 | 1/16″ | 1 x 19 | Per Foot | 427 |
| SC0621925 | 1/16″ | 1 x 19 | 250′ Spool | 427 |
| SC0621950 | 1/16″ | 1 x 19 | 500′ Spool | 427 |
| SC062191M | 1/16″ | 1 x 19 | 1,000′ Spool | 427 |
| SC062195M | 1/16″ | 1 x 19 | 5,000′ Spool | 427 |
| SC09319 | 3/32″ | 1 x 19 | Per Foot | 819 |
| SC0931925 | 3/32″ | 1 x 19 | 250′ Spool | 819 |
| SC0931950 | 3/32″ | 1 x 19 | 500′ Spool | 819 |
| SC12519 | 1/8″ | 1 x 19 | Per Foot | 1,869 |
| SC1251925 | 1/8″ | 1 x 19 | 250′ Spool | 1,869 |
| SC1251950 | 1/8″ | 1 x 19 | 500′ Spool | 1,869 |
| SC125191M | 1/8″ | 1 x 19 | 1,000′ Spool | 1,869 |
| SC125192M | 1/8″ | 1 x 19 | 2,500′ Spool | 1,869 |
| SC125195M | 1/8″ | 1 x 19 | 5,000′ Spool | 1,869 |
| SC15619 | 5/32″ | 1 x 19 | Per Foot | 2,937 |
| SC1561925 | 5/32″ | 1 x 19 | 250′ Spool | 2,937 |
| SC1561950 | 5/32″ | 1 x 19 | 500′ Spool | 2,937 |
| SC156191M | 5/32″ | 1 x 19 | 1,000′ Spool | 2,937 |
| SC156192M | 5/32″ | 1 x 19 | 2,500′ Spool | 2,937 |
| SC156195M | 5/32″ | 1 x 19 | 5,000′ Spool | 2,937 |
| SC18819 | 3/16″ | 1 x 19 | Per Foot | 4,183 |
| SC1881925 | 3/16″ | 1 x 19 | 250′ Spool | 4,183 |
| SC1881950 | 3/16″ | 1 x 19 | 500′ Spool | 4,183 |
| SC188191M | 3/16″ | 1 x 19 | 1,000′ Spool | 4,183 |
| SC188192M | 3/16″ | 1 x 19 | 2,500′ Spool | 4,183 |
| SC188195M | 3/16″ | 1 x 19 | 5,000′ Spool | 4,183 |
| SC21819 | 7/32″ | 1 x 19 | Per Foot | 5,607 |
| SC2181925 | 7/32″ | 1 x 19 | 250′ Spool | 5,607 |
| SC2181950 | 7/32″ | 1 x 19 | 500′ Spool | 5,607 |
| SC25019 | 1/4″ | 1 x 19 | Per Foot | 7,298 |
| SC2501925 | 1/4″ | 1 x 19 | 250′ Spool | 7,298 |
| SC2501950 | 1/4″ | 1 x 19 | 500′ Spool | 7,298 |
| SC250191M | 1/4″ | 1 x 19 | 1,000′ Spool | 7,298 |
| SC250182M | 1/4″ | 1 x 19 | 2,500′ Spool | 7,298 |
| SC250195M | 1/4″ | 1 x 19 | 5,000′ Spool | 7,298 |
| SC28119 | 9/32″ | 1 x 19 | Per Foot | 9,261 |
| SC2811925 | 9/32″ | 1 x 19 | 250′ Spool | 9,261 |
| SC2811950 | 9/32″ | 1 x 19 | 500′ Spool | 9,261 |
| SC281191M | 9/32″ | 1 x 19 | 1,000′ Spool | 9,261 |
| SC31219 | 5/16″ | 1 x 19 | Per Foot | 11,125 |
| SC3121925 | 5/16″ | 1 x 19 | 250′ Spool | 11,125 |
| SC3121950 | 5/16″ | 1 x 19 | 500′ Spool | 11,125 |
| SC37519 | 3/8″ | 1 x 19 | Per Foot | 15,575 |
| SC3751925 | 3/8″ | 1 x 19 | 250′ Spool | 15,575 |
| SC3751950 | 3/8″ | 1 x 19 | 500′ Spool | 15,575 |
| SC43719 | 7/16″ | 1 x 19 | Per Foot | 20,025 |
| SC4371925 | 7/16″ | 1 x 19 | 250′ Spool | 20,025 |
| SC4371950 | 7/16″ | 1 x 19 | 500′ Spool | 20,025 |
| SC50019 | 1/2″ | 1 x 19 | Per Foot | 25,116 |
| SC5001925 | 1/2″ | 1 x 19 | 250′ Spool | 25,116 |
| SC5001950 | 1/2″ | 1 x 19 | 500′ Spool | 25,116 |
| SC56219 | 9/16″ | 1 x 19 | Per Foot | 28,649 |
| SC5621925 | 9/16″ | 1 x 19 | 250′ Spool | 28,649 |
| SC62519 | 5/8″ | 1 x 19 | Per Foot | 36,107 |
| SC6251925 | 5/8″ | 1 x 19 | 250′ Spool | 36,107 |
| SC75019 | 3/4″ | 1 x 19 | Per Foot | 51,717 |
| SC87519 | 7/8″ | 1 x 19 | Per Foot | 86,590 |
| SC10037 | 1.0″ | 1 x 37 | Per Foot | 108,024 |
Compact Strand Stainless Steel Wire
| Part # | Wire Diameter | Strand Configuration | Per Foot or Spool Size | Minimum Breaking Strength LBS |
|---|---|---|---|---|
| SCM0317CS | 3mm | 1 x 7 | Per Foot | 2,205 |
| SCM0317CS25 | 3mm | 1 x 7 | 250′ Spool | 2,205 |
| SCM0317CS50 | 3mm | 1 x 7 | 500′ Spool | 2,205 |
| SCM0417CS | 4mm | 1 x 7 | Per Foot | 3,924 |
| SCM0417CS25 | 4mm | 1 x 7 | 250′ Spool | 3,924 |
| SCM0417CS50 | 4mm | 1 x 7 | 500′ Spool | 3,924 |
| SCM0519CS | 5mm | 1 x 19 | Per Foot | 5,379 |
| SCM0519CS25 | 5mm | 1 x 19 | 250′ Spool | 5,379 |
| SCM0519CS50 | 5mm | 1 x 19 | 500′ Spool | 5,379 |
| SCM0619CS | 6mm | 1 x 19 | Per Foot | 7,826 |
| SCM0619CS25 | 6mm | 1 x 19 | 250′ Spool | 7,826 |
| SCM0619CS50 | 6mm | 1 x 19 | 500′ Spool | 7,826 |
| SCM0719CS | 7mm | 1 x 19 | Per Foot | 10,825 |
| SCM0719CS25 | 7mm | 1 x 19 | 250′ Spool | 10,825 |
| SCM0719CS50 | 7mm | 1 x 19 | 500′ Spool | 10,825 |
| SCM0819CS | 8mm | 1 x 19 | Per Foot | 13,558 |
| SCM0819CS25 | 8mm | 1 x 19 | 250′ Spool | 13,558 |
| SCM0819CS50 | 8mm | 1 x 19 | 500′ Spool | 13,558 |
| SCM1019CS | 10mm | 1 x 19 | Per Foot | 21,539 |
| SCM1019CS25 | 10mm | 1 x 19 | 250′ Spool | 21,539 |
| SCM1019CS50 | 10mm | 1 x 19 | 500′ Spool | 21,539 |
| SCM1219CS | 12mm | 1 x 19 | Per Foot | 31,747 |
| SCM1219CS25 | 12mm | 1 x 19 | 250′ Spool | 31,747 |
| SCM1219CS50 | 12mm | 1 x 19 | 500′ Spool | 31,747 |
| SCM1419CS | 14mm | 1 x 19 | Per Foot | 43,415 |
| SCM1419CS25 | 14mm | 1 x 19 | 250′ Spool | 43,415 |
| SCM1419CS50 | 14mm | 1 x 19 | 500′ Spool | 43,415 |
| SCM1636CS | 16mm | 1 x 36 | Per Foot | 56,395 |
| SCM1636CS25 | 16mm | 1 x 36 | 250′ Spool | 56,395 |
| SCM1925CS | 19mm | 1 x 25 | Per Foot | 70,547 |
Metric 1×19 Stainless Steel Wire
| Part # | Wire Diameter | Strand Configuration | Per Foot or Spool Size | Minimum Breaking Strength LBS |
|---|---|---|---|---|
| SCM0419 | 4mm | 1 x 19 | Per Foot | 2,937 |
| SCM041925 | 4mm | 1 x 19 | 250′ Spool | 2,937 |
| SCM041950 | 4mm | 1 x 19 | 500′ Spool | 2,937 |
| SCM04191M | 4mm | 1 x 19 | 1,000′ Spool | 2,937 |
| SCM04192M | 4mm | 1 x 19 | 2,500′ Spool | 2,937 |
| SCM04195M | 4mm | 1 x 19 | 5,000′ Spool | 2,937 |
| SCM0519 | 5mm | 1 x 19 | Per Foot | 4,631 |
| SCM051925 | 5mm | 1 x 19 | 250′ Spool | 4,631 |
| SCM051950 | 5mm | 1 x 19 | 500′ Spool | 4,631 |
| SCM0619 | 6mm | 1 x 19 | Per Foot | 6,671 |
| SCM061925 | 6mm | 1 x 19 | 250′ Spool | 6,671 |
| SCM061950 | 6mm | 1 x 19 | 500′ Spool | 6,671 |
| SCM0719 | 7mm | 1 x 19 | Per Foot | 9,261 |
| SCM071925 | 7mm | 1 x 19 | 250′ Spool | 9,261 |
| SCM071950 | 7mm | 1 x 19 | 500′ Spool | 9,261 |
| SCM07191M | 7mm | 1 x 19 | 1,000′ Spool | 9,261 |
| SCM0819 | 8mm | 1 x 19 | Per Foot | 11,125 |
| SCM081925 | 8mm | 1 x 19 | 250′ Spool | 11,125 |
| SCM081950 | 8mm | 1 x 19 | 500′ Spool | 11,125 |
| SCM1019 | 10mm | 1 x 19 | Per Foot | 18,527 |
| SCM101925 | 10mm | 1 x 19 | 250′ Spool | 18,527 |
| SCM101950 | 10mm | 1 x 19 | 500′ Spool | 18,527 |
| SCM1219 | 12mm | 1 x 19 | Per Foot | 26,680 |
| SCM121925 | 12mm | 1 x 19 | 250′ Spool | 26,680 |
| SCM121950 | 12mm | 1 x 19 | 500′ Spool | 26,680 |
| SCM1419 | 14mm | 1 x 19 | Per Foot | 28,649 |
| SCM141925 | 14mm | 1 x 19 | 250′ Spool | 28,649 |
| SCM1619 | 16mm | 1 x 19 | Per Foot | 36,107 |
| SCM161925 | 16mm | 1 x 19 | 250′ Spool | 36,107 |
Vinyl Coated – 7×7 Stainless Steel Wire
| Part # | Wire Diameter | Strand Configuration |
Per Foot or Spool Size | Color | Vinyl Coating Diameter | Minimum Breaking Strength LBS |
|---|---|---|---|---|---|---|
| LLC11618W25 | 1/16″ | 7 x 7 | 250′ Spool | White | 1/8″ | 427 |
| LLC332532W25 | 3/32″ | 7 x 7 | 250′ Spool | White | 5/32″ | 819 |
| LLC18732W25 | 1/8″ | 7 x 7 | 250′ Spool | White | 7/32″ | 1,565 |
| LLC532732W25 | 5/32″ | 7 x 7 | 250′ Spool | White | 7/32″ | 2,136 |
| LLC316516W25 | 3/16″ | 7 x 7 | 250′ Spool | White | 5/16″ | 3,293 |
| LLC1438W25 | 1/4″ | 7 x 7 | 250′ Spool | White | 3/8″ | 5,696 |
| LLC11618W50 | 1/16″ | 7 x 7 | 500′ Spool | White | 1/8″ | 427 |
| LLC332532W50 | 3/32″ | 7 x 7 | 500′ Spool | White | 5/32″ | 819 |
| LLC18732W50 | 1/8″ | 7 x 7 | 500′ Spool | White | 7/32″ | 1,565 |
| LLC532732W50 | 5/32″ | 7 x 7 | 500′ Spool | White | 7/32″ | 2,136 |
| LLC316516W50 | 3/16″ | 7 x 7 | 500′ Spool | White | 5/16″ | 3,293 |
| LLC1438W50 | 1/4″ | 7 x 7 | 500′ Spool | White | 3/8″ | 5,696 |
| LLC11618W | 1/16″ | 7 x 7 | Per Foot | White | 1/8″ | 427 |
| LLC332532W | 3/32″ | 7 x 7 | Per Foot | White | 5/32″ | 819 |
| LLC18732W | 1/8″ | 7 x 7 | Per Foot | White | 7/32″ | 1,565 |
| LLC532732W | 5/32″ | 7 x 7 | Per Foot | White | 7/32″ | 2,136 |
| LLC316516W | 3/16″ | 7 x 7 | Per Foot | White | 5/16″ | 3,293 |
| LLC1438W | 1/4″ | 7 x 7 | Per Foot | White | 3/8″ | 5,696 |
