Larger sizes and “Pin Diameter” to “Jaw Gap” combinations available upon request.
| Hayn Part # | NAVTEC # | D – Pin Dia | A – Pin to Pin | E – Jaw Gap | F – Jaw Width | Weight lbs. |
|---|---|---|---|---|---|---|
| 14DJT | — | 1/4″ | 7/8″ | 1/4″ | 21/32″ | 0.07 |
| 516DJT | J200-1010 | 5/16″ | 31/32″ | 5/16″ | 3/4″ | 0.11 |
| 38DJT | J200-1212 | 3/8″ | 1-1/4″ | 3/8″ | 29/32″ | 0.17 |
| 38DJT-X | — | 3/8″ | 1-5/8″ | 3/8″ | 29/32″ | 0.19 |
| 716DJT | J200-1414 | 7/16″ | 1-3/4″ | 7/16″ | 1-1/16″ | 0.24 |
| 12DJT | — | 1/2″ | 1-11/16″ | 1/2″ | 1-5/32″ | 0.41 |
| 12DJT-X | J200-1616 | 1/2″ | 2.0″ | 1/2″ | 1-5/32″ | 0.64 |
| 12DJT-XX | — | 1/2″ | 2-3/16″ | 1/2″ | 1-5/32″ | 0.66 |
| 58DJT | J200-2020 | 5/8″ | 2-1/4″ | 5/8″ | 1-1/2″ | 0.79 |
| 58DJT-X | — | 5/8″ | 2-1/2″ | 5/8″ | 1-1/2″ | 1.21 |
| 58DJT-XX | — | 5/8″ | 3-5/16″ | 5/8″ | 1-1/2″ | 1.35 |
| 34DJT | J200-2424 | 3/4″ | 2-11/16 | 3/4″ | 1-7/8″ | 1.44 |
| 34DJT-X | — | 3/4″ | 3 | 3/4″ | 1-7/8″ | 2.32 |
| 34DJT-XX | — | 3/4″ | 3-1/2 | 3/4″ | 1-7/8″ | 2.45 |
| 34DJT-XXX | — | 3/4″ | 3-13/16 | 3/4″ | 1-7/8″ | 2.53 |
| 78DJT | J200-2828 | 7/8″ | 4 | 7/8″ | 2-3/8″ | 2.77 |
| 1DJT | J200-3232 | 1.0″ | 3-7/8 | 1.0″ | 2-1/2″ | 3.47 |
| 118DJT | J200-3636 | 1-1/8″ | 4 | 1-1/8″ | 2-3/4″ | 5.45 |
| 114DJT | J200-4040 | 1-1/4″ | 5-3/8 | 1-1/4″ | 3-1/4″ | 6.49 |
| 138DJT | J200-4444 | 1-3/8″ | 5-15/16 | 1-3/8″ | 4.0″ | 11.36 |
